[Amazon Bedrock AgentCore] Code Interpreterで簡単なコードを実行して画像を作成してみた

import json
import boto3
import base64
import uuid
import os
from datetime import datetime
from typing import Dict, Any
from strands import Agent, tool
from strands.models import BedrockModel
from bedrock_agentcore.runtime import BedrockAgentCoreApp
from bedrock_agentcore.tools.code_interpreter_client import code_session

app = BedrockAgentCoreApp()

# S3設定
S3_BUCKET = os.environ.get('S3_BUCKET', 'your-bucket-name')
S3_REGION = os.environ.get('AWS_REGION', 'us-west-2')

# S3クライアントを初期化（エラーハンドリング付き）
try:
    s3_client = boto3.client('s3', region_name=S3_REGION)
    S3_AVAILABLE = True
except Exception as e:
    print(f"S3 client initialization failed: {e}")
    S3_AVAILABLE = False

# システムプロンプトを短縮
SYSTEM_PROMPT = """You are a data analysis expert AI assistant.

Key principles:
1. Verify all claims with code
2. Use execute_python tool for calculations
3. Show your work through code execution
4. ALWAYS provide S3 URLs when graphs are generated

When you create visualizations:
- Graphs are automatically uploaded to S3
- Share the S3 URLs with users (valid for 1 hour)
- Clearly indicate which figure each URL represents
- IMPORTANT: Only use matplotlib for plotting. DO NOT use seaborn or other plotting libraries
- Use matplotlib's built-in styles instead of seaborn themes

Available libraries:
- pandas, numpy for data manipulation
- matplotlib.pyplot for visualization (use ONLY this for plotting)
- Basic Python libraries (json, datetime, etc.)

The execute_python tool returns JSON with:
- isError: boolean indicating if error occurred
- structuredContent: includes image_urls (S3 links) or images (base64 fallback)
- debug_info: debugging information about code execution

Always mention generated graph URLs in your response."""

@tool
def execute_python(code: str, description: str = "") -> str:
    """Execute Python code and capture any generated graphs"""

    if description:
        code = f"# {description}\n{code}"

    # Minimal image capture code
    img_code = f"""
import matplotlib
matplotlib.use('Agg')
{code}
import matplotlib.pyplot as plt,base64,io,json
imgs=[]
for i in plt.get_fignums():
 b=io.BytesIO()
 plt.figure(i).savefig(b,format='png')
 b.seek(0)
 imgs.append({{'i':i,'d':base64.b64encode(b.read()).decode()}})
if imgs:print('_IMG_'+json.dumps(imgs)+'_END_')
"""

    try:
        # Keep session open while consuming the stream to avoid premature closure/timeouts
        with code_session("us-west-2") as code_client:
            response = code_client.invoke("executeCode", {
                "code": img_code,
                "language": "python",
                "clearContext": False
            })
            # Consume stream inside the context
            result = None
            for event in response["stream"]:
                result = event["result"]
            if result is None:
                # Safeguard: ensure we return a structured result even if no events arrived
                result = {
                    "isError": True,
                    "structuredContent": {
                        "stdout": "",
                        "stderr": "No result events from Code Interpreter",
                        "exitCode": 1
                    }
                }

        # デバッグ情報を追加
        result["debug_info"] = {
            "code_size": len(img_code),
            "original_code_size": len(code),
            "img_code_preview": img_code[-200:],  # 最後の200文字
        }

        # Check for images
        stdout = result.get("structuredContent", {}).get("stdout", "")

        # デバッグ情報を拡張
        result["debug_info"]["stdout_length"] = len(stdout)
        result["debug_info"]["img_marker_found"] = "_IMG_" in stdout
        result["debug_info"]["stdout_tail"] = stdout[-300:] if len(stdout) > 300 else stdout

        if "_IMG_" in stdout and "_END_" in stdout:
            try:
                start = stdout.find("_IMG_") + 5
                end = stdout.find("_END_")
                img_json = stdout[start:end]
                imgs = json.loads(img_json)

                # デバッグ情報にイメージ数を追加
                result["debug_info"]["images_found"] = len(imgs)

                # Clean output
                clean_out = stdout[:stdout.find("_IMG_")].strip()

                # S3へのアップロードを試行
                image_urls = []
                if S3_AVAILABLE and imgs:
                    for img_data in imgs:
                        try:
                            # 画像データをデコード
                            img_bytes = base64.b64decode(img_data['d'])

                            # ユニークなファイル名を生成
                            timestamp = datetime.now().strftime('%Y%m%d_%H%M%S')
                            file_key = f"agent-outputs/{timestamp}_fig{img_data['i']}.png"

                            # S3にアップロード
                            s3_client.put_object(
                                Bucket=S3_BUCKET,
                                Key=file_key,
                                Body=img_bytes,
                                ContentType='image/png'
                            )

                            # 署名付きURLを生成（1時間有効）
                            url = s3_client.generate_presigned_url(
                                'get_object',
                                Params={'Bucket': S3_BUCKET, 'Key': file_key},
                                ExpiresIn=3600
                            )

                            image_urls.append({
                                'figure': img_data['i'],
                                'url': url,
                                's3_key': file_key
                            })

                        except Exception as e:
                            print(f"S3 upload error for figure {img_data['i']}: {e}")
                            result["debug_info"][f"s3_upload_error_fig{img_data['i']}"] = str(e)
                            result["debug_info"]["s3_fallback_message"] = "S3 upload failed, using base64 fallback"

                # Enhanced result
                result["structuredContent"]["stdout"] = clean_out

                if image_urls:
                    result["structuredContent"]["image_urls"] = image_urls
                    result["debug_info"]["s3_upload_success"] = True
                    result["debug_info"]["uploaded_count"] = len(image_urls)
                    result["debug_info"]["s3_bucket"] = S3_BUCKET
                else:
                    # S3が利用できない場合は元のbase64データを保持
                    result["structuredContent"]["images"] = imgs
                    result["debug_info"]["s3_upload_success"] = False
                    result["debug_info"]["s3_available"] = S3_AVAILABLE
                    if not S3_AVAILABLE:
                        result["debug_info"]["fallback_reason"] = "S3 client not available"

            except Exception as e:
                result["debug_info"]["image_parse_error"] = str(e)
        else:
            result["debug_info"]["images_found"] = 0

        return json.dumps(result, ensure_ascii=False)

    except Exception as e:
        # エラー時も適切なフォーマットで返す
        error_result = {
            "isError": True,
            "structuredContent": {
                "stdout": "",
                "stderr": f"Error executing code: {str(e)}",
                "exitCode": 1
            },
            "debug_info": {
                "error_type": type(e).__name__,
                "error_message": str(e),
                "code_size": len(img_code)
            }
        }
        return json.dumps(error_result, ensure_ascii=False)

model = BedrockModel(
    model_id="anthropic.claude-3-5-haiku-20241022-v1:0",
    params={"max_tokens": 4096, "temperature": 0.7},
    region="us-west-2"
)

agent = Agent(
    tools=[execute_python],
    system_prompt=SYSTEM_PROMPT,
    model=model
)

@app.entrypoint
async def code_interpreter_agent(payload: Dict[str, Any]) -> str:
    user_input = payload.get("prompt", "")

    response_text = ""
    tool_results = []

    async for event in agent.stream_async(user_input):
        if "data" in event:
            response_text += event["data"]
        # ツールの実行結果を収集
        elif "tool_result" in event:
            try:
                result = json.loads(event["tool_result"])
                if isinstance(result, dict) and "structuredContent" in result:
                    tool_results.append(result)
            except:
                pass

    # S3 URLsがある場合はレスポンスに含める
    image_urls = []
    for tool_result in tool_results:
        if "structuredContent" in tool_result and "image_urls" in tool_result["structuredContent"]:
            image_urls.extend(tool_result["structuredContent"]["image_urls"])

    if image_urls:
        response_text += "\n\n **Generated Visualizations (S3 URLs - Valid for 1 hour):**"
        for img_url_data in image_urls:
            response_text += f"\n **Figure {img_url_data['figure']}**: [View Graph]({img_url_data['url']})"
            response_text += f"\n   └── Direct Link: {img_url_data['url']}"

    return response_text

if __name__ == "__main__":
    app.run()

"""
デプロイしたCode Interpreter Agentを呼び出すテストスクリプト
"""
import boto3
import json
def invoke_code_interpreter_agent():
    """デプロイしたエージェントを呼び出し"""

    # デプロイ時に取得したAgent ARNを設定
    agent_arn = "arn:aws:bedrock-agentcore:us-west-2:YOUR_ACCOUNT_ID:runtime/YOUR_AGENT_ID"

    # 上記のagent_arnを実際の値に置き換えてから実行してください！
    if "YOUR_ACCOUNT" in agent_arn:
        print("エラー: agent_arnを実際の値に置き換えてください")
        print("   deploy_runtime.pyの実行結果から取得したAgent ARNを設定してください")
        return None

    client = boto3.client('bedrock-agentcore', region_name='us-west-2')

    # Test queries in English
    queries = [
        """Analyze the following sales data:
    - Product A: [100, 120, 95, 140, 160, 180, 200]
    - Product B: [80, 85, 90, 95, 100, 105, 110]
    - Product C: [200, 180, 220, 190, 240, 260, 280]
    Please visualize the sales trends and calculate growth rates."""
    ]

    for i, query in enumerate(queries, 1):
        print(f"\n{'='*60}")
        print(f"テスト {i}: {query}")
        print(f"{'='*60}")

        payload = json.dumps({
            "prompt": query
        }).encode('utf-8')

        try:
            response = client.invoke_agent_runtime(
                agentRuntimeArn=agent_arn,
                qualifier="DEFAULT",
                payload=payload,
                contentType='application/json',
                accept='application/json'
            )

            # レスポンスの処理
            if response.get('contentType') == 'application/json':
                content = []
                for chunk in response.get('response', []):
                    content.append(chunk.decode('utf-8'))

                try:

                    result = json.loads(''.join(content))
                    print("エージェント応答:")
                    print(result)

                except json.JSONDecodeError:
                    print("📄 Raw応答:")
                    raw_content = ''.join(content)
                    print(raw_content)

            else:
                print(f"予期しないContent-Type: {response.get('contentType')}")
                print(f"レスポンス: {response}")

        except Exception as e:
            print(f"エラー: {e}")
            if hasattr(e, 'response'):
                error_message = e.response.get('Error', {}).get('Message', 'No message')
                print(f"エラーメッセージ: {error_message}")

if __name__ == "__main__":

    invoke_code_interpreter_agent()
