printfの先をほんの少し掘ってみた

#include <stdio.h>
#include <stdlib.h>

int main()
{
  printf("Hello, world.\n");
  return 0;
}

wataru@ubuntu-24-04:~$ ldd --version
ldd (Ubuntu GLIBC 2.39-0ubuntu8.3) 2.39
Copyright (C) 2024 Free Software Foundation, Inc.
This is free software; see the source for copying conditions.  There is NO
warranty; not even for MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.
作者 Roland McGrath および Ulrich Drepper。

    :
#undef printf

/* Write formatted output to stdout from the format string FORMAT.  */
/* VARARGS1 */
int
__printf (const char *format, ...)
{
  va_list arg;
  int done;

  va_start (arg, format);
  done = __vfprintf_internal (stdout, format, arg, 0);
  va_end (arg);

  return done;
}

#undef _IO_printf
ldbl_strong_alias (__printf, printf);
ldbl_strong_alias (__printf, _IO_printf);

    :
# define vfprintf	__vfprintf_internal
    :
/* The FILE-based function.  */
int
vfprintf (FILE *s, const CHAR_T *format, va_list ap, unsigned int mode_flags)
{
  /* Orient the stream.  */
#ifdef ORIENT
  ORIENT;
#endif

  /* Sanity check of arguments.  */
  ARGCHECK (s, format);

#ifdef ORIENT
  /* Check for correct orientation.  */
  if (_IO_vtable_offset (s) == 0
      && _IO_fwide (s, sizeof (CHAR_T) == 1 ? -1 : 1)
      != (sizeof (CHAR_T) == 1 ? -1 : 1))
    /* The stream is already oriented otherwise.  */
    return EOF;
#endif

  if (!_IO_need_lock (s))
    {
      struct Xprintf (buffer_to_file) wrap;
      Xprintf (buffer_to_file_init) (&wrap, s);
      Xprintf_buffer (&wrap.base, format, ap, mode_flags);
      return Xprintf (buffer_to_file_done) (&wrap);
    }

  int done;

  /* Lock stream.  */
  _IO_cleanup_region_start ((void (*) (void *)) &_IO_funlockfile, s);
  _IO_flockfile (s);

  /* Set up the wrapping buffer.  */
  struct Xprintf (buffer_to_file) wrap;
  Xprintf (buffer_to_file_init) (&wrap, s);

  /* Perform the printing operation on the buffer.  */
  Xprintf_buffer (&wrap.base, format, ap, mode_flags);
  done = Xprintf (buffer_to_file_done) (&wrap);

  /* Unlock the stream.  */
  _IO_funlockfile (s);
  _IO_cleanup_region_end (0);

  return done;
}

    :
#define Xprintf(n) __printf_##n
    :

    :
struct __printf_buffer_to_file
{
  struct __printf_buffer base;
  FILE *fp;

  /* Staging buffer.  Used if fp does not have any available buffer
     space.  */
  char stage[PRINTF_BUFFER_SIZE_TO_FILE_STAGE];
};
    :

    :
/* The buffer-based function itself.  */
void
Xprintf_buffer (struct Xprintf_buffer *buf, const CHAR_T *format,
		  va_list ap, unsigned int mode_flags)
{
  /* The character used as thousands separator.  */
  THOUSANDS_SEP_T thousands_sep = 0;
    :
    :
/* Write the literal text before the first format.  */
  Xprintf_buffer_write (buf, format,
			  lead_str_end - (const UCHAR_T *) format);
  if (Xprintf_buffer_has_failed (buf))
    return;
    :
    :
    :
      /* Process current format.  */
      while (1)
	{
    :
    :
      /* Write the following constant string.  */
      Xprintf_buffer_write (buf, (const CHAR_T *) end_of_spec,
			      f - end_of_spec);
    }
  while (*f != L_('\0') && !Xprintf_buffer_has_failed (buf));

 all_done:
  /* printf_positional performs cleanup under its all_done label, so
     vfprintf-process-arg.c uses it for this function and
     printf_positional below.  */
  return;

  /* Hand off processing for positional parameters.  */
do_positional:
  printf_positional (buf, format, readonly_format, ap, &ap_save,
		     nspecs_done, lead_str_end, work_buffer,
		     save_errno, grouping, thousands_sep, mode_flags);
}

    :
void
Xprintf_buffer_write (struct Xprintf_buffer *buf,
                        const CHAR_T *s, size_t count)
{
  if (__glibc_unlikely (Xprintf_buffer_has_failed (buf)))
    return;

  while (count > 0)
    {
      if (buf->write_ptr == buf->write_end && !Xprintf_buffer_flush (buf))
        return;
      assert (buf->write_ptr != buf->write_end);
      size_t to_copy = buf->write_end - buf->write_ptr;
      if (to_copy > count)
        to_copy = count;
      MEMCPY (buf->write_ptr, s, to_copy);
      buf->write_ptr += to_copy;
      s += to_copy;
      count -= to_copy;
    }
}

    :
int
__printf_buffer_to_file_done (struct __printf_buffer_to_file *buf)
{
  if (__printf_buffer_has_failed (&buf->base))
    return -1;
  __printf_buffer_flush_to_file (buf);
  return __printf_buffer_done (&buf->base);
}

    :
void
__printf_buffer_flush_to_file (struct __printf_buffer_to_file *buf)
{
  /* The bytes in the buffer are always consumed.  */
  buf->base.written += buf->base.write_ptr - buf->base.write_base;

  if (buf->base.write_end == array_end (buf->stage))
    {
      /* If the stage buffer is used, make a copy into the file.  The
         stage buffer is always consumed fully, even if just partially
         written, to ensure that the file stream has all the data.  */
      size_t count = buf->base.write_ptr - buf->stage;
      if ((size_t) _IO_sputn (buf->fp, buf->stage, count) != count)
        {
          __printf_buffer_mark_failed (&buf->base);
          return;
        }
      /* buf->fp may have a buffer now.  */
      __printf_buffer_to_file_switch (buf);
      return;
    }
  else if (buf->base.write_end == buf->stage + 1)
    {
      /* Special one-character buffer case.  This is used to avoid
         flush-only overflow below.  */
      if (buf->base.write_ptr == buf->base.write_end)
        {
          if (__overflow (buf->fp, (unsigned char) *buf->stage) == EOF)
            {
              __printf_buffer_mark_failed (&buf->base);
              return;
            }
          __printf_buffer_to_file_switch (buf);
        }
      /* Else there is nothing to write.  */
      return;
    }

  /* We have written directly into the buf->fp buffer.  */
  assert (buf->base.write_end == buf->fp->_IO_write_end);

  /* Mark the bytes as written.  */
  buf->fp->_IO_write_ptr = buf->base.write_ptr;

  if (buf->base.write_ptr == buf->base.write_end)
    {
      /* The buffer in buf->fp has been filled.  This should just call
         __overflow (buf->fp, EOF), but flush-only overflow is obscure
         and not always correctly implemented.  See bug 28949.  Be
         conservative and switch to a one-character buffer instead, to
         obtain one more character for a regular __overflow call.  */
      buf->base.write_ptr = buf->stage;
      buf->base.write_end = buf->stage + 1;
    }
  /* The bytes in the file stream were already marked as written above.  */

  buf->base.write_base = buf->base.write_ptr;
}

#define _IO_sputn(__fp, __s, __n) _IO_XSPUTN (__fp, __s, __n)
    ↓↓↓
#define _IO_XSPUTN(FP, DATA, N) JUMP2 (__xsputn, FP, DATA, N)
    ↓↓↓
#define JUMP2(FUNC, THIS, X1, X2) (_IO_JUMPS_FUNC(THIS)->FUNC) (THIS, X1, X2)
    ↓↓↓
    :

    :
#include "libioP.h"
#include "stdio.h"

#undef stdin
#undef stdout
#undef stderr
FILE *stdin = (FILE *) &_IO_2_1_stdin_;
FILE *stdout = (FILE *) &_IO_2_1_stdout_;
FILE *stderr = (FILE *) &_IO_2_1_stderr_;

    :
#include "libioP.h"

#ifdef _IO_MTSAFE_IO
# define DEF_STDFILE(NAME, FD, CHAIN, FLAGS) \
  static _IO_lock_t _IO_stdfile_##FD##_lock = _IO_lock_initializer; \
  static struct _IO_wide_data _IO_wide_data_##FD \
    = { ._wide_vtable = &_IO_wfile_jumps }; \
  struct _IO_FILE_plus NAME \
    = {FILEBUF_LITERAL(CHAIN, FLAGS, FD, &_IO_wide_data_##FD), \
       &_IO_file_jumps};
#else
    :
#endif

DEF_STDFILE(_IO_2_1_stdin_, 0, 0, _IO_NO_WRITES);
DEF_STDFILE(_IO_2_1_stdout_, 1, &_IO_2_1_stdin_, _IO_NO_READS);
DEF_STDFILE(_IO_2_1_stderr_, 2, &_IO_2_1_stdout_, _IO_NO_READS+_IO_UNBUFFERED);

extern const struct _IO_jump_t __io_vtables[] attribute_hidden;
    :
#define _IO_file_jumps                   (__io_vtables[IO_FILE_JUMPS])

const struct _IO_jump_t __io_vtables[] attribute_relro =
{
  /* _IO_str_jumps  */
  [IO_STR_JUMPS] =
  {
     :
    中略
     :
  },
  /* _IO_wstr_jumps  */
  [IO_WSTR_JUMPS] = {
     :
    中略
     :
  },
  /* _IO_file_jumps  */
  [IO_FILE_JUMPS] = {
     :
    中略
     :
    JUMP_INIT (xsputn, _IO_file_xsputn),
     :
    中略
     :
  },

    :
versioned_symbol (libc, _IO_new_file_xsputn, _IO_file_xsputn, GLIBC_2_1);

size_t
_IO_new_file_xsputn (FILE *f, const void *data, size_t n)
{
  const char *s = (const char *) data;
  size_t to_do = n;
  int must_flush = 0;
  size_t count = 0;

  if (n <= 0)
    return 0;
  /* This is an optimized implementation.
     If the amount to be written straddles a block boundary
     (or the filebuf is unbuffered), use sys_write directly. */

  /* First figure out how much space is available in the buffer. */
  if ((f->_flags & _IO_LINE_BUF) && (f->_flags & _IO_CURRENTLY_PUTTING))
    {
      count = f->_IO_buf_end - f->_IO_write_ptr;
      if (count >= n)
	{
	  const char *p;
	  for (p = s + n; p > s; )
	    {
	      if (*--p == '\n')
		{
		  count = p - s + 1;
		  must_flush = 1;
		  break;
		}
	    }
	}
    }
  else if (f->_IO_write_end > f->_IO_write_ptr)
    count = f->_IO_write_end - f->_IO_write_ptr; /* Space available. */

  /* Then fill the buffer. */
  if (count > 0)
    {
      if (count > to_do)
	count = to_do;
      f->_IO_write_ptr = __mempcpy (f->_IO_write_ptr, s, count);
      s += count;
      to_do -= count;
    }
  if (to_do + must_flush > 0)
    {
      size_t block_size, do_write;
      /* Next flush the (full) buffer. */
      if (_IO_OVERFLOW (f, EOF) == EOF)
	/* If nothing else has to be written we must not signal the
	   caller that everything has been written.  */
	return to_do == 0 ? EOF : n - to_do;

      /* Try to maintain alignment: write a whole number of blocks.  */
      block_size = f->_IO_buf_end - f->_IO_buf_base;
      do_write = to_do - (block_size >= 128 ? to_do % block_size : 0);

      if (do_write)
	{
	  count = new_do_write (f, s, do_write);
	  to_do -= count;
	  if (count < do_write)
	    return n - to_do;
	}

      /* Now write out the remainder.  Normally, this will fit in the
	 buffer, but it's somewhat messier for line-buffered files,
	 so we let _IO_default_xsputn handle the general case. */
      if (to_do)
	to_do -= _IO_default_xsputn (f, s+do_write, to_do);
    }
  return n - to_do;
}

    :
static size_t
new_do_write (FILE *fp, const char *data, size_t to_do)
{
  size_t count;
  if (fp->_flags & _IO_IS_APPENDING)
    /* On a system without a proper O_APPEND implementation,
       you would need to sys_seek(0, SEEK_END) here, but is
       not needed nor desirable for Unix- or Posix-like systems.
       Instead, just indicate that offset (before and after) is
       unpredictable. */
    fp->_offset = _IO_pos_BAD;
  else if (fp->_IO_read_end != fp->_IO_write_base)
    {
      off64_t new_pos
	= _IO_SYSSEEK (fp, fp->_IO_write_base - fp->_IO_read_end, 1);
      if (new_pos == _IO_pos_BAD)
	return 0;
      fp->_offset = new_pos;
    }
  count = _IO_SYSWRITE (fp, data, to_do);
  if (fp->_cur_column && count)
    fp->_cur_column = _IO_adjust_column (fp->_cur_column - 1, data, count) + 1;
  _IO_setg (fp, fp->_IO_buf_base, fp->_IO_buf_base, fp->_IO_buf_base);
  fp->_IO_write_base = fp->_IO_write_ptr = fp->_IO_buf_base;
  fp->_IO_write_end = (fp->_mode <= 0
		       && (fp->_flags & (_IO_LINE_BUF | _IO_UNBUFFERED))
		       ? fp->_IO_buf_base : fp->_IO_buf_end);
  return count;
}

#define _IO_SYSWRITE(FP, DATA, LEN) JUMP2 (__write, FP, DATA, LEN)

    :
    JUMP_FIELD(_IO_write_t, __write);
    :

    :
    JUMP_INIT (write, _IO_new_file_write),
    :

ssize_t
_IO_new_file_write (FILE *f, const void *data, ssize_t n)
{
  ssize_t to_do = n;
  while (to_do > 0)
    {
      ssize_t count = (__builtin_expect (f->_flags2
                                         & _IO_FLAGS2_NOTCANCEL, 0)
			   ? __write_nocancel (f->_fileno, data, to_do)
			   : __write (f->_fileno, data, to_do));
      if (count < 0)
	{
	  f->_flags |= _IO_ERR_SEEN;
	  break;
	}
      to_do -= count;
      data = (void *) ((char *) data + count);
    }
  n -= to_do;
  if (f->_offset >= 0)
    f->_offset += n;
  return n;
}

    :
write		-	write		Ci:ibU	__libc_write	__write write
    :

wataru@ubuntu-24-04:~$ strace ./a.out
execve("./a.out", ["./a.out"], 0x7ffc36aabe10 /* 24 vars */) = 0
    :
   中略
    :
write(1, "Hello, world.\n", 14Hello, world.
)         = 14
exit_group(0)                           = ?
+++ exited with 0 +++

wataru@ubuntu-24-04:~$ tty
/dev/pts/0

wataru@ubuntu-24-04:~$ echo -n -e "Hello, world.\n" > /dev/pts/0
Hello, world.

wataru@ubuntu-24-04:~$ uname -r
6.8.0-41-generic

    :
0	common	read			sys_read
1	common	write			sys_write
2	common	open			sys_open
3	common	close			sys_close
4	common	stat			sys_newstat
5	common	fstat			sys_newfstat
6	common	lstat			sys_newlstat
7	common	poll			sys_poll
    :

    :
static ssize_t pty_write(struct tty_struct *tty, const u8 *buf, size_t c)
{
	struct tty_struct *to = tty->link;

	if (tty->flow.stopped || !c)
		return 0;

	return tty_insert_flip_string_and_push_buffer(to->port, buf, c);
}

    :
int tty_insert_flip_string_and_push_buffer(struct tty_port *port,
					   const u8 *chars, size_t size)
{
	struct tty_bufhead *buf = &port->buf;
	unsigned long flags;

	spin_lock_irqsave(&port->lock, flags);
	size = tty_insert_flip_string(port, chars, size);
	if (size)
		tty_flip_buffer_commit(buf->tail);
	spin_unlock_irqrestore(&port->lock, flags);

	queue_work(system_unbound_wq, &buf->work);

	return size;
}
    :

    :
static void flush_to_ldisc(struct work_struct *work)
{
	struct tty_port *port = container_of(work, struct tty_port, buf.work);
	struct tty_bufhead *buf = &port->buf;

	mutex_lock(&buf->lock);

	while (1) {
		struct tty_buffer *head = buf->head;
		struct tty_buffer *next;
		size_t count, rcvd;

		/* Ldisc or user is trying to gain exclusive access */
		if (atomic_read(&buf->priority))
			break;

		/* paired w/ release in __tty_buffer_request_room();
		 * ensures commit value read is not stale if the head
		 * is advancing to the next buffer
		 */
		next = smp_load_acquire(&head->next);
		/* paired w/ release in __tty_buffer_request_room() or in
		 * tty_buffer_flush(); ensures we see the committed buffer data
		 */
		count = smp_load_acquire(&head->commit) - head->read;
		if (!count) {
			if (next == NULL)
				break;
			buf->head = next;
			tty_buffer_free(port, head);
			continue;
		}

		rcvd = receive_buf(port, head, count);
		head->read += rcvd;
		if (rcvd < count)
			lookahead_bufs(port, head);
		if (!rcvd)
			break;

		if (need_resched())
			cond_resched();
	}

	mutex_unlock(&buf->lock);

}
    :

    :
static void n_tty_receive_buf(struct tty_struct *tty, const u8 *cp,
			      const u8 *fp, size_t count)
{
	n_tty_receive_buf_common(tty, cp, fp, count, false);
}
    ↓↓↓
static size_t
n_tty_receive_buf_common(struct tty_struct *tty, const u8 *cp, const u8 *fp,
			 size_t count, bool flow)
{
	struct n_tty_data *ldata = tty->disc_data;
	size_t n, rcvd = 0;
	int room, overflow;

	down_read(&tty->termios_rwsem);

	do {
		/*
		 * When PARMRK is set, each input char may take up to 3 chars
		 * in the read buf; reduce the buffer space avail by 3x
		 *
		 * If we are doing input canonicalization, and there are no
		 * pending newlines, let characters through without limit, so
		 * that erase characters will be handled.  Other excess
		 * characters will be beeped.
		 *
		 * paired with store in *_copy_from_read_buf() -- guarantees
		 * the consumer has loaded the data in read_buf up to the new
		 * read_tail (so this producer will not overwrite unread data)
		 */
		size_t tail = smp_load_acquire(&ldata->read_tail);

		room = N_TTY_BUF_SIZE - (ldata->read_head - tail);
		if (I_PARMRK(tty))
			room = DIV_ROUND_UP(room, 3);
		room--;
		if (room <= 0) {
			overflow = ldata->icanon && ldata->canon_head == tail;
			if (overflow && room < 0)
				ldata->read_head--;
			room = overflow;
			WRITE_ONCE(ldata->no_room, flow && !room);
		} else
			overflow = 0;

		n = min_t(size_t, count, room);
		if (!n)
			break;

		/* ignore parity errors if handling overflow */
		if (!overflow || !fp || *fp != TTY_PARITY)
			__receive_buf(tty, cp, fp, n);

		cp += n;
		if (fp)
			fp += n;
		count -= n;
		rcvd += n;
	} while (!test_bit(TTY_LDISC_CHANGING, &tty->flags));

	tty->receive_room = room;

	/* Unthrottle if handling overflow on pty */
	if (tty->driver->type == TTY_DRIVER_TYPE_PTY) {
		if (overflow) {
			tty_set_flow_change(tty, TTY_UNTHROTTLE_SAFE);
			tty_unthrottle_safe(tty);
			__tty_set_flow_change(tty, 0);
		}
	} else
		n_tty_check_throttle(tty);

	if (unlikely(ldata->no_room)) {
		/*
		 * Barrier here is to ensure to read the latest read_tail in
		 * chars_in_buffer() and to make sure that read_tail is not loaded
		 * before ldata->no_room is set.
		 */
		smp_mb();
		if (!chars_in_buffer(tty))
			n_tty_kick_worker(tty);
	}

	up_read(&tty->termios_rwsem);

	return rcvd;
}
    ↓↓↓
static void __receive_buf(struct tty_struct *tty, const u8 *cp, const u8 *fp,
			  size_t count)
{
	struct n_tty_data *ldata = tty->disc_data;
	bool preops = I_ISTRIP(tty) || (I_IUCLC(tty) && L_IEXTEN(tty));
	size_t la_count = min(ldata->lookahead_count, count);

	if (ldata->real_raw)
		n_tty_receive_buf_real_raw(tty, cp, count);
	else if (ldata->raw || (L_EXTPROC(tty) && !preops))
		n_tty_receive_buf_raw(tty, cp, fp, count);
	else if (tty->closing && !L_EXTPROC(tty)) {
		if (la_count > 0) {
			n_tty_receive_buf_closing(tty, cp, fp, la_count, true);
			cp += la_count;
			if (fp)
				fp += la_count;
			count -= la_count;
		}
		if (count > 0)
			n_tty_receive_buf_closing(tty, cp, fp, count, false);
	} else {
		if (la_count > 0) {
			n_tty_receive_buf_standard(tty, cp, fp, la_count, true);
			cp += la_count;
			if (fp)
				fp += la_count;
			count -= la_count;
		}
		if (count > 0)
			n_tty_receive_buf_standard(tty, cp, fp, count, false);

		flush_echoes(tty);
		if (tty->ops->flush_chars)
			tty->ops->flush_chars(tty);
	}

	ldata->lookahead_count -= la_count;

	if (ldata->icanon && !L_EXTPROC(tty))
		return;

	/* publish read_head to consumer */
	smp_store_release(&ldata->commit_head, ldata->read_head);

	if (read_cnt(ldata)) {
		kill_fasync(&tty->fasync, SIGIO, POLL_IN);
		wake_up_interruptible_poll(&tty->read_wait, EPOLLIN | EPOLLRDNORM);
	}
}
    ↓↓↓
static void flush_echoes(struct tty_struct *tty)
{
	struct n_tty_data *ldata = tty->disc_data;

	if ((!L_ECHO(tty) && !L_ECHONL(tty)) ||
	    ldata->echo_commit == ldata->echo_head)
		return;

	mutex_lock(&ldata->output_lock);
	ldata->echo_commit = ldata->echo_head;
	__process_echoes(tty);
	mutex_unlock(&ldata->output_lock);
}
    ↓↓↓
static size_t __process_echoes(struct tty_struct *tty)
{
	struct n_tty_data *ldata = tty->disc_data;
	int	space, old_space;
	size_t tail;
	u8 c;

	old_space = space = tty_write_room(tty);

	tail = ldata->echo_tail;
	while (MASK(ldata->echo_commit) != MASK(tail)) {
		c = echo_buf(ldata, tail);
		if (c == ECHO_OP_START) {
			int ret = n_tty_process_echo_ops(tty, &tail, space);
			if (ret == -ENODATA)
				goto not_yet_stored;
			if (ret < 0)
				break;
			space = ret;
		} else {
			if (O_OPOST(tty)) {
				int retval = do_output_char(c, tty, space);
				if (retval < 0)
					break;
				space -= retval;
			} else {
				if (!space)
					break;
				tty_put_char(tty, c);
				space -= 1;
			}
			tail += 1;
		}
	}

	/* If the echo buffer is nearly full (so that the possibility exists
	 * of echo overrun before the next commit), then discard enough
	 * data at the tail to prevent a subsequent overrun */
	while (ldata->echo_commit > tail &&
	       ldata->echo_commit - tail >= ECHO_DISCARD_WATERMARK) {
		if (echo_buf(ldata, tail) == ECHO_OP_START) {
			if (echo_buf(ldata, tail + 1) == ECHO_OP_ERASE_TAB)
				tail += 3;
			else
				tail += 2;
		} else
			tail++;
	}

 not_yet_stored:
	ldata->echo_tail = tail;
	return old_space - space;
}
    ↓↓↓
static int do_output_char(u8 c, struct tty_struct *tty, int space)
{
	struct n_tty_data *ldata = tty->disc_data;
	int	spaces;

	if (!space)
		return -1;

	switch (c) {
	case '\n':
		if (O_ONLRET(tty))
			ldata->column = 0;
		if (O_ONLCR(tty)) {
			if (space < 2)
				return -1;
			ldata->canon_column = ldata->column = 0;
			tty->ops->write(tty, "\r\n", 2);
			return 2;
		}
		ldata->canon_column = ldata->column;
		break;
	case '\r':
		if (O_ONOCR(tty) && ldata->column == 0)
			return 0;
		if (O_OCRNL(tty)) {
			c = '\n';
			if (O_ONLRET(tty))
				ldata->canon_column = ldata->column = 0;
			break;
		}
		ldata->canon_column = ldata->column = 0;
		break;
	case '\t':
		spaces = 8 - (ldata->column & 7);
		if (O_TABDLY(tty) == XTABS) {
			if (space < spaces)
				return -1;
			ldata->column += spaces;
			tty->ops->write(tty, "        ", spaces);
			return spaces;
		}
		ldata->column += spaces;
		break;
	case '\b':
		if (ldata->column > 0)
			ldata->column--;
		break;
	default:
		if (!iscntrl(c)) {
			if (O_OLCUC(tty))
				c = toupper(c);
			if (!is_continuation(c, tty))
				ldata->column++;
		}
		break;
	}

	tty_put_char(tty, c);
	return 1;
}

int tty_put_char(struct tty_struct *tty, u8 ch)
{
	if (tty->ops->put_char)
		return tty->ops->put_char(tty, ch);
	return tty->ops->write(tty, &ch, 1);
}
EXPORT_SYMBOL_GPL(tty_put_char);

static int con_put_char(struct tty_struct *tty, u8 ch)
{
	return do_con_write(tty, &ch, 1);
}
    ↓↓↓
static int do_con_write(struct tty_struct *tty, const u8 *buf, int count)
{
	struct vc_draw_region draw = {
		.x = -1,
	};
	int c, tc, n = 0;
	unsigned int currcons;
	struct vc_data *vc = tty->driver_data;
	struct vt_notifier_param param;
	bool rescan;

	if (in_interrupt())
		return count;

	console_lock();
	currcons = vc->vc_num;
	if (!vc_cons_allocated(currcons)) {
		/* could this happen? */
		pr_warn_once("con_write: tty %d not allocated\n", currcons+1);
		console_unlock();
		return 0;
	}

	/* undraw cursor first */
	if (con_is_fg(vc))
		hide_cursor(vc);

	param.vc = vc;

	while (!tty->flow.stopped && count) {
		u8 orig = *buf;
		buf++;
		n++;
		count--;
rescan_last_byte:
		c = orig;
		rescan = false;

		tc = vc_translate(vc, &c, &rescan);
		if (tc == -1)
			continue;

		param.c = tc;
		if (atomic_notifier_call_chain(&vt_notifier_list, VT_PREWRITE,
					&param) == NOTIFY_STOP)
			continue;

		if (vc_is_control(vc, tc, c)) {
			con_flush(vc, &draw);
			do_con_trol(tty, vc, orig);
			continue;
		}

		if (vc_con_write_normal(vc, tc, c, &draw) < 0)
			continue;

		if (rescan)
			goto rescan_last_byte;
	}
	con_flush(vc, &draw);
	console_conditional_schedule();
	notify_update(vc);
	console_unlock();
	return n;
}
    ↓↓↓
static void con_flush(struct vc_data *vc, struct vc_draw_region *draw)
{
	if (draw->x < 0)
		return;

	vc->vc_sw->con_putcs(vc, (u16 *)draw->from,
			(u16 *)draw->to - (u16 *)draw->from, vc->state.y,
			draw->x);
	draw->x = -1;
}

static void fbcon_putcs(struct vc_data *vc, const u16 *s, unsigned int count,
			unsigned int ypos, unsigned int xpos)
{
	struct fb_info *info = fbcon_info_from_console(vc->vc_num);
	struct fbcon_display *p = &fb_display[vc->vc_num];
	struct fbcon_ops *ops = info->fbcon_par;

	if (!fbcon_is_inactive(vc, info))
		ops->putcs(vc, info, s, count, real_y(p, ypos), xpos,
			   get_color(vc, info, scr_readw(s), 1),
			   get_color(vc, info, scr_readw(s), 0));
}

static void bit_putcs(struct vc_data *vc, struct fb_info *info,
		      const unsigned short *s, int count, int yy, int xx,
		      int fg, int bg)
{
	struct fb_image image;
	u32 width = DIV_ROUND_UP(vc->vc_font.width, 8);
	u32 cellsize = width * vc->vc_font.height;
	u32 maxcnt = info->pixmap.size/cellsize;
	u32 scan_align = info->pixmap.scan_align - 1;
	u32 buf_align = info->pixmap.buf_align - 1;
	u32 mod = vc->vc_font.width % 8, cnt, pitch, size;
	u32 attribute = get_attribute(info, scr_readw(s));
	u8 *dst, *buf = NULL;

	image.fg_color = fg;
	image.bg_color = bg;
	image.dx = xx * vc->vc_font.width;
	image.dy = yy * vc->vc_font.height;
	image.height = vc->vc_font.height;
	image.depth = 1;

	if (attribute) {
		buf = kmalloc(cellsize, GFP_ATOMIC);
		if (!buf)
			return;
	}

	while (count) {
		if (count > maxcnt)
			cnt = maxcnt;
		else
			cnt = count;

		image.width = vc->vc_font.width * cnt;
		pitch = DIV_ROUND_UP(image.width, 8) + scan_align;
		pitch &= ~scan_align;
		size = pitch * image.height + buf_align;
		size &= ~buf_align;
		dst = fb_get_buffer_offset(info, &info->pixmap, size);
		image.data = dst;

		if (!mod)
			bit_putcs_aligned(vc, info, s, attribute, cnt, pitch,
					  width, cellsize, &image, buf, dst);
		else
			bit_putcs_unaligned(vc, info, s, attribute, cnt,
					    pitch, width, cellsize, &image,
					    buf, dst);

		image.dx += cnt * vc->vc_font.width;
		count -= cnt;
		s += cnt;
	}

	/* buf is always NULL except when in monochrome mode, so in this case
	   it's a gain to check buf against NULL even though kfree() handles
	   NULL pointers just fine */
	if (unlikely(buf))
		kfree(buf);

}
