[アップデート] Amazon Bedrock AgentCore Runtime に Amazon S3 Files をネイティブマウントできるようになりました

AWSTemplateFormatVersion: "2010-09-09"
Description: VPC + S3 Files (FileSystem + MountTargets + AccessPoint) for AgentCore Runtime verification

Parameters:
  Suffix:
    Type: String
    Default: fsverify

Resources:
  # ---- VPC ----
  Vpc:
    Type: AWS::EC2::VPC
    Properties:
      CidrBlock: 10.20.0.0/16
      EnableDnsSupport: true
      EnableDnsHostnames: true
      Tags: [{Key: Name, Value: !Sub "${Suffix}-vpc"}]

  Igw:
    Type: AWS::EC2::InternetGateway
    Properties:
      Tags: [{Key: Name, Value: !Sub "${Suffix}-igw"}]

  IgwAttach:
    Type: AWS::EC2::VPCGatewayAttachment
    Properties:
      VpcId: !Ref Vpc
      InternetGatewayId: !Ref Igw

  # ---- Private subnets (AgentCore Runtime ENI + S3 Files Mount Target) ----
  SubnetA:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.20.1.0/24
      AvailabilityZone: !Select [0, !GetAZs ""]
      MapPublicIpOnLaunch: false
      Tags: [{Key: Name, Value: !Sub "${Suffix}-private-a"}]

  SubnetB:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.20.2.0/24
      AvailabilityZone: !Select [1, !GetAZs ""]
      MapPublicIpOnLaunch: false
      Tags: [{Key: Name, Value: !Sub "${Suffix}-private-b"}]

  # ---- Public subnets (for NAT Gateway) ----
  PublicSubnetA:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.20.101.0/24
      AvailabilityZone: !Select [0, !GetAZs ""]
      MapPublicIpOnLaunch: true
      Tags: [{Key: Name, Value: !Sub "${Suffix}-public-a"}]

  PublicSubnetB:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.20.102.0/24
      AvailabilityZone: !Select [1, !GetAZs ""]
      MapPublicIpOnLaunch: true
      Tags: [{Key: Name, Value: !Sub "${Suffix}-public-b"}]

  # ---- NAT Gateway (in PublicSubnetA) ----
  EipNat:
    Type: AWS::EC2::EIP
    Properties:
      Domain: vpc
      Tags: [{Key: Name, Value: !Sub "${Suffix}-eip-nat"}]

  NatGateway:
    Type: AWS::EC2::NatGateway
    DependsOn: IgwAttach
    Properties:
      AllocationId: !GetAtt EipNat.AllocationId
      SubnetId: !Ref PublicSubnetA
      Tags: [{Key: Name, Value: !Sub "${Suffix}-nat"}]

  # ---- Public route table ----
  PublicRt:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref Vpc
      Tags: [{Key: Name, Value: !Sub "${Suffix}-public-rt"}]

  PublicRtIgwRoute:
    Type: AWS::EC2::Route
    DependsOn: IgwAttach
    Properties:
      RouteTableId: !Ref PublicRt
      DestinationCidrBlock: 0.0.0.0/0
      GatewayId: !Ref Igw

  PublicRtAssocA:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref PublicSubnetA
      RouteTableId: !Ref PublicRt

  PublicRtAssocB:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref PublicSubnetB
      RouteTableId: !Ref PublicRt

  # ---- Private route table (NAT + S3 Gateway Endpoint) ----
  Rt:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref Vpc
      Tags: [{Key: Name, Value: !Sub "${Suffix}-private-rt"}]

  RtDefault:
    Type: AWS::EC2::Route
    Properties:
      RouteTableId: !Ref Rt
      DestinationCidrBlock: 0.0.0.0/0
      NatGatewayId: !Ref NatGateway

  RtAssocA:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref SubnetA
      RouteTableId: !Ref Rt

  RtAssocB:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref SubnetB
      RouteTableId: !Ref Rt

  # ---- Security Group (self-referenced NFS 2049) ----
  Sg:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: !Sub "${Suffix} S3 Files NFS"
      VpcId: !Ref Vpc
      Tags: [{Key: Name, Value: !Sub "${Suffix}-sg"}]

  SgIngressNfsSelf:
    Type: AWS::EC2::SecurityGroupIngress
    Properties:
      GroupId: !Ref Sg
      IpProtocol: tcp
      FromPort: 2049
      ToPort: 2049
      SourceSecurityGroupId: !Ref Sg

  # ---- S3 Gateway VPC Endpoint (free, used for ECR layer pulls) ----
  EndpointS3:
    Type: AWS::EC2::VPCEndpoint
    Properties:
      VpcId: !Ref Vpc
      ServiceName: !Sub "com.amazonaws.${AWS::Region}.s3"
      VpcEndpointType: Gateway
      RouteTableIds: [!Ref Rt]

  # ---- S3 bucket (versioning + SSE-S3) ----
  Bucket:
    Type: AWS::S3::Bucket
    DeletionPolicy: Delete
    UpdateReplacePolicy: Delete
    Properties:
      BucketName: !Sub "${Suffix}-${AWS::AccountId}-${AWS::Region}"
      VersioningConfiguration:
        Status: Enabled
      BucketEncryption:
        ServerSideEncryptionConfiguration:
          - ServerSideEncryptionByDefault:
              SSEAlgorithm: AES256

  # ---- IAM role assumed by S3 Files service ----
  S3FilesServiceRole:
    Type: AWS::IAM::Role
    Properties:
      RoleName: !Sub "${Suffix}-s3files-service-role"
      AssumeRolePolicyDocument:
        Version: "2012-10-17"
        Statement:
          - Effect: Allow
            Principal: {Service: elasticfilesystem.amazonaws.com}
            Action: sts:AssumeRole
            Condition:
              StringEquals: {aws:SourceAccount: !Ref AWS::AccountId}
              ArnLike: {aws:SourceArn: !Sub "arn:aws:s3files:${AWS::Region}:${AWS::AccountId}:file-system/*"}
      Policies:
        - PolicyName: s3files-bucket-access
          PolicyDocument:
            Version: "2012-10-17"
            Statement:
              - Sid: S3BucketPermissions
                Effect: Allow
                Action: [s3:ListBucket, s3:ListBucketVersions]
                Resource: !GetAtt Bucket.Arn
                Condition:
                  StringEquals: {aws:ResourceAccount: !Ref AWS::AccountId}
              - Sid: S3ObjectPermissions
                Effect: Allow
                Action:
                  - s3:AbortMultipartUpload
                  - s3:DeleteObject*
                  - s3:GetObject*
                  - s3:List*
                  - s3:PutObject*
                Resource: !Sub "${Bucket.Arn}/*"
                Condition:
                  StringEquals: {aws:ResourceAccount: !Ref AWS::AccountId}
              - Sid: EventBridgeManage
                Effect: Allow
                Action: [events:DeleteRule, events:DisableRule, events:EnableRule, events:PutRule, events:PutTargets, events:RemoveTargets]
                Condition:
                  StringEquals: {events:ManagedBy: elasticfilesystem.amazonaws.com}
                Resource: arn:aws:events:*:*:rule/DO-NOT-DELETE-S3-Files*
              - Sid: EventBridgeRead
                Effect: Allow
                Action: [events:DescribeRule, events:ListRuleNamesByTarget, events:ListRules, events:ListTargetsByRule]
                Resource: arn:aws:events:*:*:rule/*

  # ---- S3 Files: FileSystem ----
  FileSystem:
    Type: AWS::S3Files::FileSystem
    DependsOn: S3FilesServiceRole
    Properties:
      Bucket: !GetAtt Bucket.Arn
      RoleArn: !GetAtt S3FilesServiceRole.Arn
      AcceptBucketWarning: true
      Tags:
        - Key: Name
          Value: !Sub "${Suffix}-fs"

  # ---- S3 Files: Mount Targets (one per private subnet) ----
  MountTargetA:
    Type: AWS::S3Files::MountTarget
    Properties:
      FileSystemId: !Ref FileSystem
      SubnetId: !Ref SubnetA
      SecurityGroups: [!Ref Sg]

  MountTargetB:
    Type: AWS::S3Files::MountTarget
    Properties:
      FileSystemId: !Ref FileSystem
      SubnetId: !Ref SubnetB
      SecurityGroups: [!Ref Sg]

  # ---- S3 Files: Access Point ----
  AccessPoint:
    Type: AWS::S3Files::AccessPoint
    Properties:
      FileSystemId: !Ref FileSystem
      PosixUser:
        Uid: 1000
        Gid: 1000
      RootDirectory:
        Path: /agent
        CreationPermissions:
          OwnerUid: 1000
          OwnerGid: 1000
          Permissions: "0755"
      Tags:
        - Key: Name
          Value: !Sub "${Suffix}-ap"

  # ---- AgentCore Runtime role ----
  RuntimeRole:
    Type: AWS::IAM::Role
    Properties:
      RoleName: !Sub "${Suffix}-runtime-role"
      AssumeRolePolicyDocument:
        Version: "2012-10-17"
        Statement:
          - Effect: Allow
            Principal: {Service: bedrock-agentcore.amazonaws.com}
            Action: sts:AssumeRole
            Condition:
              StringEquals: {aws:SourceAccount: !Ref AWS::AccountId}
              ArnLike: {aws:SourceArn: !Sub "arn:aws:bedrock-agentcore:${AWS::Region}:${AWS::AccountId}:*"}
      Policies:
        - PolicyName: ecr-pull
          PolicyDocument:
            Version: "2012-10-17"
            Statement:
              - Effect: Allow
                Action: [ecr:BatchGetImage, ecr:GetDownloadUrlForLayer, ecr:GetAuthorizationToken]
                Resource: "*"
        - PolicyName: cloudwatch-logs
          PolicyDocument:
            Version: "2012-10-17"
            Statement:
              - Effect: Allow
                Action: [logs:CreateLogGroup, logs:CreateLogStream, logs:PutLogEvents, logs:DescribeLogStreams]
                Resource: !Sub "arn:aws:logs:*:${AWS::AccountId}:log-group:/aws/bedrock-agentcore/*"
        - PolicyName: workload-identity
          PolicyDocument:
            Version: "2012-10-17"
            Statement:
              - Effect: Allow
                Action:
                  - bedrock-agentcore:GetWorkloadAccessToken
                  - bedrock-agentcore:GetWorkloadAccessTokenForJWT
                  - bedrock-agentcore:GetWorkloadAccessTokenForUserId
                Resource: "*"
        - PolicyName: s3files-client
          PolicyDocument:
            Version: "2012-10-17"
            Statement:
              - Effect: Allow
                Action: [s3files:*, elasticfilesystem:*]
                Resource: "*"

Outputs:
  VpcId: {Value: !Ref Vpc}
  SubnetIds: {Value: !Sub "${SubnetA},${SubnetB}"}
  SecurityGroupId: {Value: !Ref Sg}
  BucketName: {Value: !Ref Bucket}
  FileSystemId: {Value: !Ref FileSystem}
  AccessPointArn: {Value: !GetAtt AccessPoint.AccessPointArn}
  RuntimeRoleArn: {Value: !GetAtt RuntimeRole.Arn}
