Kiro ヘッドレスLambda + AssumeRoleでGuardDuty Findingを自動トリアージを試してみた

AWSTemplateFormatVersion: '2010-09-09'
Description: 'Kiro Headless Lambda (AssumeRole) - Stack 2: Lambda + CloudWatch Role + SNS'

Parameters:
  ImageUri:
    Type: String
    Description: ECR Image URI (from Stack 1 CodeBuild output)

Resources:
  # SNS Topic for alerts
  AlertTopic:
    Type: AWS::SNS::Topic
    Properties:
      TopicName: kiro-guardduty-alerts

  # Lambda実行ロール: 最小権限 (自身のログ + SSM + AssumeRole + SNS)
  LambdaRole:
    Type: AWS::IAM::Role
    Properties:
      RoleName: KiroLambdaRole
      AssumeRolePolicyDocument:
        Version: '2012-10-17'
        Statement:
          - Effect: Allow
            Principal:
              Service: lambda.amazonaws.com
            Action: sts:AssumeRole
      ManagedPolicyArns:
        - arn:aws:iam::aws:policy/service-role/AWSLambdaBasicExecutionRole
      Policies:
        - PolicyName: KiroLambdaMinimal
          PolicyDocument:
            Version: '2012-10-17'
            Statement:
              - Sid: SsmApiKey
                Effect: Allow
                Action: ssm:GetParameter
                Resource: !Sub 'arn:aws:ssm:${AWS::Region}:${AWS::AccountId}:parameter/kiro/headless/api-key'
              - Sid: KmsDecrypt
                # SSM SecureStringの復号用。実運用では対象KMSキーARNに絞ることを推奨
                Effect: Allow
                Action: kms:Decrypt
                Resource: '*'
              - Sid: AssumeTargetRoles
                Effect: Allow
                Action: sts:AssumeRole
                Resource: !GetAtt KiroCloudWatchRole.Arn
              - Sid: SnsPublish
                Effect: Allow
                Action: sns:Publish
                Resource: !Ref AlertTopic
              - Sid: GuardDutyReadArchive
                Effect: Allow
                Action:
                  - guardduty:GetFindings
                  - guardduty:ArchiveFindings
                Resource: !Sub 'arn:aws:guardduty:*:${AWS::AccountId}:detector/*'

  # AssumeRole先: VPCフローログのLogs Insights調査用
  KiroCloudWatchRole:
    Type: AWS::IAM::Role
    Properties:
      RoleName: KiroCloudWatchRole
      AssumeRolePolicyDocument:
        Version: '2012-10-17'
        Statement:
          - Effect: Allow
            Principal:
              AWS: !Sub 'arn:aws:iam::${AWS::AccountId}:root'
            Action: sts:AssumeRole
      Policies:
        - PolicyName: FlowLogInsightsOnly
          PolicyDocument:
            Version: '2012-10-17'
            Statement:
              - Sid: LogsInsightsQuery
                Effect: Allow
                Action:
                  - logs:StartQuery
                  - logs:GetQueryResults
                  - logs:StopQuery
                Resource: !Sub 'arn:aws:logs:${AWS::Region}:${AWS::AccountId}:log-group:/vpc/sushiro-test-flow-logs:*'
              - Sid: DescribeLogGroups
                Effect: Allow
                Action: logs:DescribeLogGroups
                Resource: !Sub 'arn:aws:logs:${AWS::Region}:${AWS::AccountId}:log-group:*'

  KiroLambda:
    Type: AWS::Lambda::Function
    Properties:
      FunctionName: kiro-headless
      PackageType: Image
      Code:
        ImageUri: !Ref ImageUri
      Architectures:
        - arm64
      Role: !GetAtt LambdaRole.Arn
      Timeout: 600
      MemorySize: 512
      Environment:
        Variables:
          SNS_TOPIC_ARN: !Ref AlertTopic

Outputs:
  LambdaFunction:
    Value: !Ref KiroLambda
  LambdaArn:
    Value: !GetAtt KiroLambda.Arn
  KiroCloudWatchRoleArn:
    Value: !GetAtt KiroCloudWatchRole.Arn
    Export:
      Name: KiroCloudWatchRoleArn
  AlertTopicArn:
    Value: !Ref AlertTopic

import subprocess
import os
import time
import re
import json

import boto3

_ansi_re = re.compile(r'\x1b\[[0-9;]*m')

ssm = boto3.client("ssm", region_name=os.environ.get("AWS_REGION", "us-east-1"))
sts = boto3.client("sts")
_api_key_cache = None

def get_api_key():
    global _api_key_cache
    if not _api_key_cache:
        _api_key_cache = os.environ.get("KIRO_API_KEY")
        if not _api_key_cache:
            resp = ssm.get_parameter(Name="/kiro/headless/api-key", WithDecryption=True)
            _api_key_cache = resp["Parameter"]["Value"]
    return _api_key_cache

def assume_role(role_arn):
    resp = sts.assume_role(RoleArn=role_arn, RoleSessionName="kiro-headless")
    creds = resp["Credentials"]
    return {
        "AWS_ACCESS_KEY_ID": creds["AccessKeyId"],
        "AWS_SECRET_ACCESS_KEY": creds["SecretAccessKey"],
        "AWS_SESSION_TOKEN": creds["SessionToken"],
    }

def parse_verdict(output):
    for line in reversed(output.strip().splitlines()):
        if line.startswith("VERDICT:"):
            return line.split(":", 1)[1].strip()
    return None

def handler(event, context):
    timings = {}
    t0 = time.time()

    # --- 前処理: GuardDuty Finding のアーカイブ判定 ---
    finding_id = event.get("finding_id")
    detector_id = event.get("detector_id")
    finding_json = None

    if finding_id and detector_id:
        gd_region = event.get("guardduty_region", "ap-northeast-1")
        gd = boto3.client("guardduty", region_name=gd_region)
        findings = gd.get_findings(DetectorId=detector_id, FindingIds=[finding_id])["Findings"]
        if not findings:
            return {"statusCode": 200, "result": "Finding not found, skipped.", "timings": {}}
        if findings[0]["Service"]["Archived"]:
            return {"statusCode": 200, "result": "Finding already archived, skipped.", "timings": {}}
        finding_json = json.dumps(findings[0], default=str)

    # --- プロンプト構築 ---
    prompt = event.get("prompt", "")
    if finding_json:
        prompt = f"{prompt}\n\nFinding JSON:\n{finding_json}"
    if not prompt or len(prompt.strip()) < 10:
        return {"statusCode": 400, "error": "Prompt too short (min 10 chars)"}

    # VERDICT出力を指示
    prompt += "\n\n最終行に必ず VERDICT:SAFE または VERDICT:ALERT を出力して。"

    # --- Kiro実行 ---
    api_key = get_api_key()
    env = {**os.environ, "KIRO_API_KEY": api_key, "HOME": "/tmp"}

    role_arn = event.get("role_arn")
    if role_arn:
        env.update(assume_role(role_arn))

    start = time.time()
    result = subprocess.run(
        ["/usr/local/bin/kiro-cli", "chat", "--no-interactive", "--trust-all-tools", prompt],
        capture_output=True, text=True, timeout=280, env=env,
    )
    timings["kiro_execution"] = round(time.time() - start, 2)

    if result.returncode != 0:
        timings["total"] = round(time.time() - t0, 2)
        return {
            "statusCode": 500,
            "error": result.stderr.strip() or f"kiro-cli exited with code {result.returncode}",
            "timings": timings,
        }

    output = _ansi_re.sub('', result.stdout.strip())

    # --- 後処理: VERDICT に基づく分岐 ---
    verdict = parse_verdict(output)
    action_taken = None

    if finding_id and detector_id:
        gd_region = event.get("guardduty_region", "ap-northeast-1")
        gd = boto3.client("guardduty", region_name=gd_region)
        sns_topic = os.environ.get("SNS_TOPIC_ARN")

        if verdict == "SAFE":
            gd.archive_findings(DetectorId=detector_id, FindingIds=[finding_id])
            action_taken = "archived"
        elif verdict == "ALERT":
            if sns_topic:
                sns = boto3.client("sns", region_name=os.environ.get("AWS_REGION", "us-east-1"))
                sns.publish(
                    TopicArn=sns_topic,
                    Subject=f"GuardDuty ALERT: {event.get('finding_id', 'unknown')}",
                    Message=output,
                )
            action_taken = "sns_notified"
        else:
            # パース失敗 → 安全側に倒してSNS通知
            if sns_topic:
                sns = boto3.client("sns", region_name=os.environ.get("AWS_REGION", "us-east-1"))
                sns.publish(
                    TopicArn=sns_topic,
                    Subject=f"GuardDuty VERDICT_UNKNOWN: {event.get('finding_id', 'unknown')}",
                    Message=f"VERDICT parse failed.\n\n{output}",
                )
            action_taken = "sns_notified_parse_fail"

    timings["total"] = round(time.time() - t0, 2)

    return {
        "statusCode": 200,
        "prompt": event.get("prompt", ""),
        "role_arn": role_arn,
        "verdict": verdict,
        "action_taken": action_taken,
        "result": output,
        "timings": timings,
    }

{
  "statusCode": 200,
  "prompt": "このGuardDuty Findingを調査して。ap-northeast-1のロググループ /vpc/sushiro-test-flow-logs をLogs Insightsでクエリし、該当インスタンスからC2ドメインへの実TCP通信があるか確認して。検索範囲: start-time=1779807062 end-time=1779814262。実害有無を判定して。",
  "role_arn": "arn:aws:iam::123456789012:role/KiroCloudWatchRole",
  "verdict": "SAFE",
  "action_taken": "archived",
  "result": "> ## GuardDuty Finding 調査\n\n### Finding概要\n\n| 項目 | 値 |\n|------|-----|\n| Type | Backdoor:EC2/C&CActivity.B!DNS |\n| Severity | 8.0 (High) |\n| Instance | i-0abc1234def56789 (10.0.1.100 / xx.xx.xx.xx) |\n| C2ドメイン | guarddutyc2activityb.com |\n| アクション | DNS_REQUEST (UDP) |\n| Blocked | false |\n| 初回/最終検知 | 2026-05-26T15:51:02Z |\n\nこのFindingはDNSクエリのみを検知しています。実際にTCP通信（データ送受信）があったかをVPC Flow Logsで確認します。\n\n### VPC Flow Logs クエリ\n\nC2ドメインへの実TCP通信があるか、該当インスタンスのENI eni-0abc1234def56789 からの通信を確認します。\nRunning aws cli command (using tool: aws):\n\nService name: logs\nOperation name: start-query\nParameters: \n- --start-time: \"1779807062\"\n- --log-group-name: \"/vpc/sushiro-test-flow-logs\"\n- --end-time: \"1779814262\"\n- --query-string: \"fields @timestamp, srcAddr, dstAddr, srcPort, dstPort, protocol, action, bytes, packets | filter srcAddr = '10.0.1.100' and protocol = 6 | sort @timestamp desc | limit 50\"\nRegion: ap-northeast-1\nLabel: Query VPC Flow Logs for TCP traffic from the instance - Completed in 5.432s\n\nI will run the following command: sleep 5 (using tool: shell)\nPurpose: Wait for CloudWatch Logs Insights query to complete\n\n - Completed in 5.17s\n\nRunning aws cli command (using tool: aws):\n\nService name: logs\nOperation name: get-query-results\nParameters: \n- --query-id: \"c21b65c4-737c-441f-b1a8-70968b700f16\"\nRegion: ap-northeast-1\nLabel: Get query results for TCP traffic from the instance - Completed in 5.325s\n\n> ### 分析結果\n\nVPC Flow Logsから、インスタンス 10.0.1.100 のTCP通信（protocol=6）を確認しました。通信先は以下のIPアドレスです：\n\n| 宛先IP | ポート | 特徴 |\n|--------|--------|------|\n| 52.xxx.xxx.106 | 443 | 最も頻繁。約1分間隔で継続的に通信（keepalive的） |\n| 52.xxx.xxx.15 | 443 | AWS系IP。SSM/CloudFormation等のAWSサービス通信 |\n| 52.xxx.xxx.146 | 443 | AWS系IP |\n| 52.xxx.xxx.191 | 443 | AWS系IP |\n| 52.xxx.xxx.57 | 443 | AWS系IP |\n| 52.xxx.xxx.50 | 443 | AWS系IP |\n| 52.xxx.xxx.20 | 443 | S3エンドポイント（52.219.x.x はS3） |\n| 52.xxx.xxx.146 | 443 | S3エンドポイント |\n| 3.xxx.xxx.148 | 443 | AWS系IP（ap-northeast-1） |\n\n### 判定\n\n実害なし（テスト環境のGuardDutyサンプルFinding）\n\n根拠：\n\n1. C2ドメインへの実TCP通信は確認されない: guarddutyc2activityb.com はGuardDutyのテスト用ドメインとして知られています。FindingのアクションタイプはDNS_REQUEST（UDP）のみで、このドメインのIPへのTCP接続はFlow Logsに存在しません。\n\n2. 通信先はすべてAWSサービスIP: 検出されたTCP通信はすべて 52.195.x.x（EC2/SSM等のAWSサービスエンドポイント）、52.219.x.x（S3）、3.112.x.x（AWS ap-northeast-1）宛のポート443通信であり、正常なAWSサービス通信です。\n\n3. テスト環境の証拠:\n   - スタック名: GuardDutyTestEc2\n   - インスタンス名: guardduty-test\n   - IAMプロファイル名に GuardDutyTestEc2 を含む\n   - インスタンス起動からFinding検知まで約6分（テスト実行パターン）\n\n4. DNSクエリのみでデータ流出なし: DNS解決は行われたが、解決先IPへのTCPセッション確立（実際のC2通信）は発生していません。\n\nVERDICT:SAFE",
  "timings": {"kiro_execution": 50.59, "total": 53.24}
}
