Terraformを使ってEKSを作成してみた

はじめに

おはようございます､加藤です｡Terraformを使ってEKSを作成してみました｡

やってみた

解説

コードはGitHubにアップしています｡すぐにデプロイしたい場合はクローンして使用してください｡

vpc.tf

data "aws_availability_zones" "available" {}

resource "aws_vpc" "vpc" {
  cidr_block           = "${var.vpc_cidr_block}"
  enable_dns_hostnames = true
  enable_dns_support   = true
  tags                 = "${merge(local.default_tags, map("Name", "${local.base_name}-vpc"))}"
}

resource "aws_subnet" "subnet" {
  count                   = "${var.num_subnets}"
  vpc_id                  = "${aws_vpc.vpc.id}"
  availability_zone       = "${data.aws_availability_zones.available.names[ count.index % var.num_subnets ]}"
  cidr_block              = "${cidrsubnet(var.vpc_cidr_block, 8, count.index + var.num_subnets * 0 )}"
  map_public_ip_on_launch = true

  tags = "${merge(local.default_tags, map("Name", "${local.base_name}-subnet-${count.index+1}"))}"
}

resource "aws_internet_gateway" "igw" {
  vpc_id = "${aws_vpc.vpc.id}"

  tags = "${merge(local.default_tags, map("Name", "${local.base_name}-igw"))}"
}

resource "aws_route_table" "rtb" {
  vpc_id = "${aws_vpc.vpc.id}"

  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = "${aws_internet_gateway.igw.id}"
  }

  tags = "${merge(local.default_tags, map("Name", "${local.base_name}-rtb"))}"
}

resource "aws_route_table_association" "rtba" {
  count          = "${var.num_subnets}"
  subnet_id      = "${element(aws_subnet.subnet.*.id, count.index)}"
  route_table_id = "${aws_route_table.rtb.id}"
}

Publicなサブネットのみで作成します｡num_subnetsで作成するサブネットの個数を設定しています｡(デフォルトは3個) また､EKSで使用する場合は､VPCリソースには下記のタグが必須なので対応しています｡

key	value
kubernetes.io/cluster/	shared

iam.tf

resource "aws_iam_role" "eks-master-role" {
  name = "eks-master-role"

  assume_role_policy = <<EOS
{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Action": "sts:AssumeRole",
      "Principal": {
        "Service": "eks.amazonaws.com"
      },
      "Effect": "Allow"
    }
  ]
}
EOS
}

resource "aws_iam_role_policy_attachment" "eks-cluster-policy" {
  policy_arn = "arn:aws:iam::aws:policy/AmazonEKSClusterPolicy"
  role       = "${aws_iam_role.eks-master-role.name}"
}

resource "aws_iam_role_policy_attachment" "eks-service-policy" {
  policy_arn = "arn:aws:iam::aws:policy/AmazonEKSServicePolicy"
  role       = "${aws_iam_role.eks-master-role.name}"
}

resource "aws_iam_role" "eks-node-role" {
  name = "eks-node-role"

  assume_role_policy = <<EOS
{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Action": "sts:AssumeRole",
      "Principal": {
        "Service": "ec2.amazonaws.com"
      },
      "Effect": "Allow"
    }
  ]
}
EOS
}

resource "aws_iam_role_policy_attachment" "eks-worker-node-policy" {
  policy_arn = "arn:aws:iam::aws:policy/AmazonEKSWorkerNodePolicy"
  role       = "${aws_iam_role.eks-node-role.name}"
}

resource "aws_iam_role_policy_attachment" "eks-cni-policy" {
  policy_arn = "arn:aws:iam::aws:policy/AmazonEKS_CNI_Policy"
  role       = "${aws_iam_role.eks-node-role.name}"
}

resource "aws_iam_role_policy_attachment" "ec2-container-registry-readonly" {
  policy_arn = "arn:aws:iam::aws:policy/AmazonEC2ContainerRegistryReadOnly"
  role       = "${aws_iam_role.eks-node-role.name}"
}

resource "aws_iam_role_policy_attachment" "ec2-role-for-ssm" {
  policy_arn = "arn:aws:iam::aws:policy/service-role/AmazonEC2RoleforSSM"
  role       = "${aws_iam_role.eks-node-role.name}"
}

resource "aws_iam_instance_profile" "eks-node-role-profile" {
  name = "eks-node-role-profile"
  role = "${aws_iam_role.eks-node-role.name}"
}

EKSのマスター､ノード用のIAMロール､インスタンスプロファイルを作成します｡ ノードに対してコマンドを実行する際にはSSHではなくSSMを想定して､AmazonEC2RoleforSSMを割り当てています｡

security_group.tf

resource "aws_security_group" "cluster-master" {
  name        = "cluster-master"
  description = "EKS cluster master security group"

  tags = "${merge(local.default_tags,map("Name","eks-master-sg"))}"

  vpc_id = "${aws_vpc.vpc.id}"

  ingress {
    from_port   = 443
    to_port     = 443
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }
}

resource "aws_security_group" "cluster-nodes" {
  name        = "cluster-nodes"
  description = "EKS cluster nodes security group"

  tags   = "${merge(local.default_tags,map("Name","eks-nodes-sg"))}"
  vpc_id = "${aws_vpc.vpc.id}"

  ingress {
    description = "Allow cluster master to access cluster nodes"
    from_port   = 1025
    to_port     = 65535
    protocol    = "tcp"

    security_groups = ["${aws_security_group.cluster-master.id}"]
  }

  ingress {
    description = "Allow cluster master to access cluster nodes"
    from_port   = 1025
    to_port     = 65535
    protocol    = "udp"

    security_groups = ["${aws_security_group.cluster-master.id}"]
  }

  ingress {
    description = "Allow inter pods communication"
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    self        = true
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }
}

Egressは全許可でIngressは下記の様に許可します｡今回はLBの許可は行っていません｡

送信元	通信内容	送信先
ALL(0.0.0.0/0)	TCP/443	マスター
マスター	TCP&UDP/Dynamic Port	ノード
ノード	ALL	ノード

eks.tf

locals {
  kubeconfig = <<KUBECONFIG
apiVersion: v1
clusters:
- cluster:
    server: ${aws_eks_cluster.eks-cluster.endpoint}
    certificate-authority-data: ${aws_eks_cluster.eks-cluster.certificate_authority.0.data}
  name: kubernetes
contexts:
- context:
    cluster: kubernetes
    user: aws
  name: aws
current-context: aws
kind: Config
preferences: {}
users:
- name: aws
  user:
    exec:
      apiVersion: client.authentication.k8s.io/v1alpha1
      command: aws-iam-authenticator
      args:
        - "token"
        - "-i"
        - "${local.cluster_name}"
KUBECONFIG

  eks_configmap = <<CONFIGMAPAWSAUTH
apiVersion: v1
kind: ConfigMap
metadata:
  name: aws-auth
  namespace: kube-system
data:
  mapRoles: |
    - rolearn: ${aws_iam_role.eks-node-role.arn}
      username: system:node:{{EC2PrivateDNSName}}
      groups:
        - system:bootstrappers
        - system:nodes
CONFIGMAPAWSAUTH
}

resource "aws_eks_cluster" "eks-cluster" {
  name     = "${local.cluster_name}"
  role_arn = "${aws_iam_role.eks-master-role.arn}"
  version  = "${local.cluster_version}"

  vpc_config {
    security_group_ids = ["${aws_security_group.cluster-master.id}"]

    subnet_ids = ["${aws_subnet.subnet.*.id}"]
  }

  depends_on = [
    "aws_iam_role_policy_attachment.eks-cluster-policy",
    "aws_iam_role_policy_attachment.eks-service-policy",
  ]
}

EKSの作成部分です｡アウトプットする為のkubeconfig,configmapをlocalに格納しておきます｡

asg.tf

resource "aws_autoscaling_group" "eks-asg" {
  name                 = "EKS cluster nodes"
  desired_capacity     = "${var.num_subnets}"
  launch_configuration = "${aws_launch_configuration.eks-lc.id}"
  max_size             = "${var.num_subnets}"
  min_size             = "${var.num_subnets}"

  vpc_zone_identifier = ["${aws_subnet.subnet.*.id}"]

  tag {
    key                 = "Name"
    value               = "${local.base_name}-nodes"
    propagate_at_launch = true
  }

  tag {
    key                 = "kubernetes.io/cluster/${local.cluster_name}"
    value               = "owned"
    propagate_at_launch = true
  }

  tag {
    key                 = "Project"
    value               = "${var.project}"
    propagate_at_launch = true
  }

  tag {
    key                 = "Terraform"
    value               = "true"
    propagate_at_launch = true
  }

  tag {
    key                 = "Environment"
    value               = "${var.environment}"
    propagate_at_launch = true
  }

  lifecycle {
    create_before_destroy = true
  }
}

ノード用のAutoScalingグループを作成します｡desired_capacity, min_size, max_sizeをnum_subnetsにしています｡num_subnets=3の場合だと基本的に､各サブネットに1台で立ち上がります｡ 台数を増やしたい場合は､*2などで対応すると良いと思います｡ また､EKSで使用する場合は､EC2インスタンスには下記のタグが必須なので対応しています｡

key	value
kubernetes.io/cluster/	owned

launch_config.tf

locals {
  userdata = <<USERDATA
#!/bin/bash
set -o xtrace
/etc/eks/bootstrap.sh --apiserver-endpoint "${aws_eks_cluster.eks-cluster.endpoint}" --b64-cluster-ca "${aws_eks_cluster.eks-cluster.certificate_authority.0.data}" "${aws_eks_cluster.eks-cluster.name}"
USERDATA
}

data "aws_ami" "eks-node" {
  most_recent = true
  owners      = ["602401143452"]

  filter {
    name   = "name"
    values = ["amazon-eks-node-${local.cluster_version}-*"]
  }
}

data "aws_ami" "eks-gpu-node" {
  most_recent = true
  owners      = ["679593333241"]

  filter {
    name   = "name"
    values = ["amazon-eks-gpu-node-${local.cluster_version}-*"]
  }
}

resource "aws_launch_configuration" "eks-lc" {
  associate_public_ip_address = true
  iam_instance_profile        = "${aws_iam_instance_profile.eks-node-role-profile.id}"
  image_id                    = "${data.aws_ami.eks-node.image_id}"
  instance_type               = "t3.medium"
  name_prefix                 = "eks-node"
  key_name                    = "${var.key_name}"
  enable_monitoring           = false

  root_block_device {
    volume_type = "gp2"
    volume_size = "50"
  }

  security_groups  = ["${aws_security_group.cluster-nodes.id}"]
  user_data_base64 = "${base64encode(local.userdata)}"

  lifecycle {
    create_before_destroy = true
  }
}

AutoScalingグループ用の起動設定です｡data "aws_ami"を使って使用するk8sバージョン用の最新のAMIを参照してきます｡ GPU用のAMIを定義だけしておきました｡

outputs.tf

output "kubectl config" {
  value = "${local.kubeconfig}"
}

output "EKS ConfigMap" {
  value = "${local.eks_configmap}"
}

kubeconfig, configmapをコンソールに出力する設定です｡

variable "region" {
  default = "us-west-2"
}

variable "project" {
  default = "eks"
}

variable "environment" {
  default = "dev"
}

variable "vpc_cidr_block" {
  default = "10.0.0.0/16"
}

variable "num_subnets" {
  default = 3
}

variable "key_name" {
  default = "your_key_name"
}

locals {
  base_tags = {
    Project     = "${var.project}"
    Terraform   = "true"
    Environment = "${var.environment}"
  }

  default_tags    = "${merge(local.base_tags, map("kubernetes.io/cluster/${local.cluster_name}", "shared"))}"
  base_name       = "${var.project}-${var.environment}"
  cluster_name    = "${local.base_name}-cluster"
  cluster_version = "1.10"
}

variable, localの設定です｡

デプロイ

EKSを作成します｡

terraform plan
terraform apply -var 'key_name=YOUR_KEY_NAME'

terraform output の結果をそれぞれファイルに保存する｡

• EKS ConfigMap → manifests/config_map.yml
• kubectl config → .kube/config

terraform output kubectl_config > .kube/config
terraform output ConfigMap > manifests/config_map.yml

以下のコマンドを実行する｡

export KUBECONFIG='.kube/config'
kubectl apply -f manifests/config_map.yml

ノードがReadyになって居ることを確認する｡

kubectl get nodes

あとがき

今回はその利点を生かしていませんが､CloudFormationと比べTerraformはAWS以外､特にKubenetesに対してもInfrastructure as Codeが行えるというメリットがあります｡ 今は手動で対応が必要な部分が多く､ELBに対応していませんが､徐々に成長させて行こうと思います｡
