LINE DC Generative AI Meetup #6 で「LINE Messaging API × OpenAI APIで入力音声の文字起こしBot作ってみた」というテーマで登壇しました

line-transcriptions-bot/
├── infra/          // インフラ
│   ├── lib/
│   │   └── infra-stack.ts // スタック定義
│   ├── bin/
│   │   └── infra.ts
│   └── config.ts
├── server/         // バックエンド
│   ├── src/
│   │   ├── index.ts // handler
│   │   └── services/
│   │       └── openai.ts
└── └── package.json

import * as cdk from 'aws-cdk-lib';
import * as lambda from 'aws-cdk-lib/aws-lambda';
import { NodejsFunction } from 'aws-cdk-lib/aws-lambda-nodejs';
import * as apigateway from 'aws-cdk-lib/aws-apigateway';
import { Construct } from 'constructs';
import { Config } from '../config-type';

type InfraStackProps = cdk.StackProps & {
  config: Config;
};

export class InfraStack extends cdk.Stack {
  constructor(scope: Construct, id: string, props: InfraStackProps) {
    super(scope, id, props);

    // Lambda関数の作成
    const lineTranscriptionLambda = new NodejsFunction(this, 'LineTranscriptionFunction', {
      runtime: lambda.Runtime.NODEJS_LATEST,
      entry: '../server/src/index.ts',
      handler: 'handler',
      timeout: cdk.Duration.seconds(30),
      environment: {
+       LINE_CHANNEL_ACCESS_TOKEN: props.config.LINE_CHANNEL_ACCESS_TOKEN,
+       LINE_CHANNEL_SECRET: props.config.LINE_CHANNEL_SECRET,
+       OPENAI_API_KEY: props.config.OPENAI_API_KEY,
      },
    });

    // API Gatewayの作成
    const api = new apigateway.RestApi(this, 'LineTranscriptionApi', {
      restApiName: 'LINE Transcription Bot API',
      description: 'LINE音声文字起こしBot用のAPI Gateway',
      defaultCorsPreflightOptions: {
        allowOrigins: apigateway.Cors.ALL_ORIGINS,
        allowMethods: apigateway.Cors.ALL_METHODS,
      },
    });

    // Webhookエンドポイントの作成
    const webhookIntegration = new apigateway.LambdaIntegration(lineTranscriptionLambda);
    // https://domain/webhook にPOSTリクエストを受け付ける
+   api.root.addResource('webhook').addMethod('POST', webhookIntegration);
  }
}

import { APIGatewayProxyEvent, APIGatewayProxyResult } from 'aws-lambda';
import {  WebhookEvent, MessageEvent, validateSignature, messagingApi, middleware, LINE_SIGNATURE_HTTP_HEADER_NAME  } from '@line/bot-sdk';
import { transcribeAudio } from './services/openai';

const LINE_CHANNEL_ACCESS_TOKEN = process.env.LINE_CHANNEL_ACCESS_TOKEN ?? "";
const LINE_CHANNEL_SECRET = process.env.LINE_CHANNEL_SECRET ?? "";

const client = new messagingApi.MessagingApiClient({
  channelAccessToken: LINE_CHANNEL_ACCESS_TOKEN,
});

const blobClient = new messagingApi.MessagingApiBlobClient({
  channelAccessToken: LINE_CHANNEL_ACCESS_TOKEN,
});

middleware({
  channelSecret: LINE_CHANNEL_SECRET,
});

export const handler = async (
  event: APIGatewayProxyEvent
): Promise<APIGatewayProxyResult> => {
  console.debug("handler開始", event);
  try {
    // リクエストボディの取得
    const body = event.body;
    if (!body) {
      return {
        statusCode: 400,
        body: JSON.stringify({ message: 'Request body is required' }),
      };
    }

    // LINEのWebhookからのリクエストであることを検証 @see: https://dev.classmethod.jp/articles/line-messaging-api-for-nodejs/
+   const signature = event.headers[LINE_SIGNATURE_HTTP_HEADER_NAME]
+   if (!validateSignature(event.body!, LINE_CHANNEL_SECRET, signature!)) {
+     console.error("Invalid signature");
+     return {
+       statusCode: 403,
+       body: 'Invalid signature',
+     };
+   }

    // Webhookイベントの解析
    const webhookEvents: WebhookEvent[] = JSON.parse(body).events;

    // 各イベントを処理
    await Promise.all(
      webhookEvents.map(async (webhookEvent) => {
        if (webhookEvent.type === 'message' && webhookEvent.message.type === 'audio') {
+         await handleAudioMessage(webhookEvent);
        }
      })
    );

    const response = {
      statusCode: 200,
      body: JSON.stringify({ message: 'OK' }),
    };

    console.debug("handler終了", response);
    return response;
  } catch (error) {
    console.error('Error processing webhook:', error);
    return {
      statusCode: 500,
      body: JSON.stringify({ message: 'Internal server error' }),
    };
  }
};

async function handleAudioMessage(event: MessageEvent) {
  console.debug("handleAudioMessage開始", event);
  try {
    const messageId = event.message.id;
    const replyToken = event.replyToken;

    // LINEから音声データを取得
    const audioStream = await blobClient.getMessageContent(messageId);

    // 音声データをバッファに変換
    const audioBuffer = await streamToBuffer(audioStream);
    // OpenAI APIで文字起こし
+   const transcription = await transcribeAudio(audioBuffer);

    // 結果をLINEに返信
+   await client.replyMessage({
+     replyToken: replyToken,
+     messages: [{
+       type: 'text',
+       text: `🗣️\n${transcription}`,
+     }]
+   });

  } catch (error) {
    console.error('Error handling audio message:', error);

    // エラーメッセージを返信
    if ('replyToken' in event) {
      await client.replyMessage({
        replyToken: event.replyToken,
        messages: [{
          type: 'text',
          text: '音声の文字起こしに失敗しました。もう一度お試しください。',
        }]
      });
    }
  }
}

async function streamToBuffer(stream: NodeJS.ReadableStream): Promise<Buffer> {
  return new Promise((resolve, reject) => {
    const chunks: Buffer[] = [];
    stream.on('data', (chunk) => chunks.push(chunk));
    stream.on('end', () => resolve(Buffer.concat(chunks)));
    stream.on('error', reject);
  });
}

import OpenAI from 'openai';
import { toFile } from 'openai';

const openai = new OpenAI({
  apiKey: process.env.OPENAI_API_KEY!,
});

export async function transcribeAudio(audioBuffer: Buffer): Promise<string> {
  try {
    // BufferをOpenAI SDKが期待するFile形式に変換
    const audioFile = await toFile(audioBuffer, 'audio.m4a', {
      type: 'audio/m4a'
    });

    // OpenAI gpt-4o-transcribeで文字起こし
+   const transcription = await openai.audio.transcriptions.create({
+     file: audioFile,
+     model: 'gpt-4o-transcribe',
+     response_format: 'text',
+     language: 'ja', // 日本語を指定
+     prompt: '以下は日本語の音声です。正確に文字起こししてください。',
+   });

    return transcription;
  } catch (error) {
    console.error('Error transcribing audio:', error);

    // フォールバックとして異なる音声形式を試す（mp3）
    try {
      const audioFile = await toFile(audioBuffer, 'audio.mp3', {
        type: 'audio/mp3'
      });

      const transcription = await openai.audio.transcriptions.create({
        file: audioFile,
        model: 'gpt-4o-transcribe',
        response_format: 'text',
        language: 'ja',
        prompt: '以下は日本語の音声です。正確に文字起こししてください。',
      });

      return transcription;
    } catch (fallbackError) {
      console.error('Error with fallback transcription:', fallbackError);
      throw new Error('音声の文字起こしに失敗しました');
    }
  }
}
