Kiro が Kimi K3 をサポート、Claude、GPT のモデルと成果物を比較してみた

AWSTemplateFormatVersion: '2010-09-09'
Description: Sample EC2 stack with security group, EBS volume, ENI, EIP and launch template

Parameters:
  VpcId:
    Type: AWS::EC2::VPC::Id
  SubnetId:
    Type: AWS::EC2::Subnet::Id
  LatestAmiId:
    Type: AWS::SSM::Parameter::Value<AWS::EC2::Image::Id>
    Default: /aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-x86_64

Resources:
  Ec2SsmRole:
    Type: AWS::IAM::Role
    Properties:
      AssumeRolePolicyDocument:
        Version: '2012-10-17'
        Statement:
          - Effect: Allow
            Principal:
              Service: ec2.amazonaws.com
            Action: sts:AssumeRole
      ManagedPolicyArns:
        - arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore

  Ec2InstanceProfile:
    Type: AWS::IAM::InstanceProfile
    Properties:
      Roles:
        - !Ref Ec2SsmRole

  AppSG:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Security group for the application
      VpcId: !Ref VpcId
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: 22
          ToPort: 22
          CidrIp: 0.0.0.0/0
        - IpProtocol: tcp
          FromPort: 3389
          ToPort: 3389
          CidrIp: 0.0.0.0/0
        - IpProtocol: tcp
          FromPort: 22
          ToPort: 22
          CidrIpv6: '::/0'
        - IpProtocol: tcp
          FromPort: 3389
          ToPort: 3389
          CidrIpv6: '::/0'
        - IpProtocol: tcp
          FromPort: 8080
          ToPort: 8080
          CidrIp: 0.0.0.0/0
        - IpProtocol: tcp
          FromPort: 3306
          ToPort: 3306
          CidrIp: 0.0.0.0/0
        - IpProtocol: tcp
          FromPort: 5432
          ToPort: 5432
          CidrIp: 0.0.0.0/0

  AuxSG:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Security group for auxiliary use
      VpcId: !Ref VpcId

  AppInstance:
    Type: AWS::EC2::Instance
    Properties:
      InstanceType: t3.micro
      ImageId: !Ref LatestAmiId
      IamInstanceProfile: !Ref Ec2InstanceProfile
      MetadataOptions:
        HttpTokens: optional
        HttpEndpoint: enabled
      NetworkInterfaces:
        - DeviceIndex: 0
          SubnetId: !Ref SubnetId
          AssociatePublicIpAddress: true
          GroupSet:
            - !Ref AppSG

  DataVolume:
    Type: AWS::EC2::Volume
    Properties:
      AvailabilityZone: !GetAtt AppInstance.AvailabilityZone
      Size: 1
      Encrypted: false

  VolumeAttachment:
    Type: AWS::EC2::VolumeAttachment
    Properties:
      Device: /dev/xvdf
      InstanceId: !Ref AppInstance
      VolumeId: !Ref DataVolume

  ExtraENI:
    Type: AWS::EC2::NetworkInterface
    Properties:
      SubnetId: !Ref SubnetId
      GroupSet:
        - !Ref AppSG
      SourceDestCheck: false

  ENIAttachment:
    Type: AWS::EC2::NetworkInterfaceAttachment
    Properties:
      DeviceIndex: 1
      InstanceId: !Ref AppInstance
      NetworkInterfaceId: !Ref ExtraENI

  SpareEIP:
    Type: AWS::EC2::EIP
    Properties:
      Domain: vpc

  AppLaunchTemplate:
    Type: AWS::EC2::LaunchTemplate
    Properties:
      LaunchTemplateData:
        InstanceType: t3.micro
        ImageId: !Ref LatestAmiId
        MetadataOptions:
          HttpTokens: optional
          HttpEndpoint: enabled
        NetworkInterfaces:
          - DeviceIndex: 0
            AssociatePublicIpAddress: true
            Groups:
              - !Ref AppSG
        BlockDeviceMappings:
          - DeviceName: /dev/xvda
            Ebs:
              VolumeSize: 8
              Encrypted: false

Outputs:
  InstanceId:
    Value: !Ref AppInstance
  SecurityGroupId:
    Value: !Ref AppSG

AWSTemplateFormatVersion: '2010-09-09'
Description: Three-tier web application (ALB, EC2, RDS) in a new VPC across two AZs

Parameters:
  LatestAmiId:
    Type: AWS::SSM::Parameter::Value<AWS::EC2::Image::Id>
    Default: /aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-x86_64
  InstanceType:
    Type: String
    Default: t3.micro
  DbInstanceClass:
    Type: String
    Default: db.t3.micro

Resources:
  Vpc:
    Type: AWS::EC2::VPC
    Properties:
      CidrBlock: 10.0.0.0/16
      EnableDnsSupport: true
      EnableDnsHostnames: true
      Tags:
        - Key: Name
          Value: web3-vpc

  Igw:
    Type: AWS::EC2::InternetGateway

  IgwAttachment:
    Type: AWS::EC2::VPCGatewayAttachment
    Properties:
      VpcId: !Ref Vpc
      InternetGatewayId: !Ref Igw

  PublicSubnetA:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.0.0.0/24
      AvailabilityZone: ap-northeast-1a
  PublicSubnetC:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.0.1.0/24
      AvailabilityZone: ap-northeast-1c
  AppSubnetA:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.0.10.0/24
      AvailabilityZone: ap-northeast-1a
  AppSubnetC:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.0.11.0/24
      AvailabilityZone: ap-northeast-1c
  DbSubnetA:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.0.20.0/24
      AvailabilityZone: ap-northeast-1a
  DbSubnetC:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref Vpc
      CidrBlock: 10.0.21.0/24
      AvailabilityZone: ap-northeast-1c

  PublicRouteTable:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref Vpc
  PublicDefaultRoute:
    Type: AWS::EC2::Route
    DependsOn: IgwAttachment
    Properties:
      RouteTableId: !Ref PublicRouteTable
      DestinationCidrBlock: 0.0.0.0/0
      GatewayId: !Ref Igw
  PublicSubnetAAssoc:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref PublicSubnetA
      RouteTableId: !Ref PublicRouteTable
  PublicSubnetCAssoc:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref PublicSubnetC
      RouteTableId: !Ref PublicRouteTable

  NatEip:
    Type: AWS::EC2::EIP
    Properties:
      Domain: vpc
  NatGateway:
    Type: AWS::EC2::NatGateway
    Properties:
      AllocationId: !GetAtt NatEip.AllocationId
      SubnetId: !Ref PublicSubnetA

  AppRouteTable:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref Vpc
  AppDefaultRoute:
    Type: AWS::EC2::Route
    Properties:
      RouteTableId: !Ref AppRouteTable
      DestinationCidrBlock: 0.0.0.0/0
      NatGatewayId: !Ref NatGateway
  AppSubnetAAssoc:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref AppSubnetA
      RouteTableId: !Ref AppRouteTable
  AppSubnetCAssoc:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref AppSubnetC
      RouteTableId: !Ref AppRouteTable

  DbRouteTable:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref Vpc
  DbSubnetAAssoc:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref DbSubnetA
      RouteTableId: !Ref DbRouteTable
  DbSubnetCAssoc:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref DbSubnetC
      RouteTableId: !Ref DbRouteTable

  AlbSg:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: ALB
      VpcId: !Ref Vpc
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: 80
          ToPort: 80
          CidrIp: 0.0.0.0/0
  AppSg:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: App servers
      VpcId: !Ref Vpc
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: 8080
          ToPort: 8080
          SourceSecurityGroupId: !Ref AlbSg
  DbSg:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Database
      VpcId: !Ref Vpc
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: 3306
          ToPort: 3306
          SourceSecurityGroupId: !Ref AppSg

  Alb:
    Type: AWS::ElasticLoadBalancingV2::LoadBalancer
    Properties:
      Type: application
      Scheme: internet-facing
      Subnets:
        - !Ref PublicSubnetA
        - !Ref PublicSubnetC
      SecurityGroups:
        - !Ref AlbSg
  AppTargetGroup:
    Type: AWS::ElasticLoadBalancingV2::TargetGroup
    Properties:
      VpcId: !Ref Vpc
      Protocol: HTTP
      Port: 8080
      TargetType: instance
      HealthCheckPath: /health
      Targets:
        - Id: !Ref AppInstanceA
        - Id: !Ref AppInstanceC
  HttpListener:
    Type: AWS::ElasticLoadBalancingV2::Listener
    Properties:
      LoadBalancerArn: !Ref Alb
      Protocol: HTTP
      Port: 80
      DefaultActions:
        - Type: forward
          TargetGroupArn: !Ref AppTargetGroup

  AppInstanceA:
    Type: AWS::EC2::Instance
    Properties:
      ImageId: !Ref LatestAmiId
      InstanceType: !Ref InstanceType
      SubnetId: !Ref AppSubnetA
      SecurityGroupIds:
        - !Ref AppSg
  AppInstanceC:
    Type: AWS::EC2::Instance
    Properties:
      ImageId: !Ref LatestAmiId
      InstanceType: !Ref InstanceType
      SubnetId: !Ref AppSubnetC
      SecurityGroupIds:
        - !Ref AppSg

  DbSubnetGroup:
    Type: AWS::RDS::DBSubnetGroup
    Properties:
      DBSubnetGroupDescription: Database subnets
      SubnetIds:
        - !Ref DbSubnetA
        - !Ref DbSubnetC
  Database:
    Type: AWS::RDS::DBInstance
    Properties:
      Engine: mysql
      DBInstanceClass: !Ref DbInstanceClass
      AllocatedStorage: 20
      MultiAZ: true
      PubliclyAccessible: false
      DBSubnetGroupName: !Ref DbSubnetGroup
      VPCSecurityGroups:
        - !Ref DbSg
      MasterUsername: admin
      ManageMasterUserPassword: true

次の CloudFormation テンプレートの構成図を、draw.io（diagrams.net）で開ける形式で作ってください。ツールは使えません。

要件:
- 回答は、`.drawio` ファイルの中身全体（`<mxfile>` から `</mxfile>` まで、圧縮なしの XML）を、```xml のコードブロック 1 つだけで出してください。ブロックは回答の中で 1 つにしてください
- AWS のアーキテクチャアイコン（draw.io の AWS 図形）を使う
- VPC とサブネットは枠（グループ）で表し、リソースを置いた場所が分かるようにする
- リソース間の関係や通信の流れを、線（矢印）でつなぐ
- アイコンと枠には、リソースの名前が分かるラベルを付ける
- 描くのは、サービス名のラベルを付けたアイコン、線、エリア（枠）だけにする。XML のコメント、凡例、注記や説明のテキスト図形、線の上のラベルは入れない

構成図の見た目や配置の細部は任せます。
